Corral Panels with Galvanized Steel Tubing for Livestock Containment and Farm Enclosures
Corral panels are heavy-duty steel enclosures designed for livestock containment and management. Made from galvanized round or square tubing with 4–6 rails, panels range from 1.5–1.8 m high and 2.1–3.6 m long. Tubes are 25–60 mm diameter with 1.6–2.0 mm thickness, ensuring durability and strength. Hot-dip galvanized or powder-coated finishes resist rust for long-term use. Corral panels feature interlocking pin or clamp connections, optional gates, and stable foot designs, making them ideal for cattle, horses, and farm enclosures.
Specifications
1. Material and Finish
- Material: Heavy-duty galvanized steel tubing
- Finish: Hot-dip galvanized or powder-coated for corrosion resistance
2. Panel Height
- Common heights: 1.5 m, 1.6 m, 1.8 m
3. Panel Length
- Standard lengths: 2.1 m, 2.4 m, 3.0 m, 3.6 m、
4. Tube Specifications
- Round or square tubing: 25 mm, 32 mm, 42 mm, 48 mm, 60 mm diameter
- Wall thickness: 1.6 mm, 1.8 mm, 2.0 mm
5. Rails and Spacing
- Number of rails: 4, 5, or 6 horizontal rails
- Rail spacing: 200 mm–300 mm center-to-center
6. Connections and Accessories
- Interlocking pin or clamp system for secure connections
- Optional swing or walk-through gates with chain latches
7. Feet and Base Options
- Welded saddle or flat-foot plates for ground stability
- Portable or permanent installation options
Applications
- Livestock Enclosures: Used to create safe holding areas for cattle, horses, sheep, and other livestock.
- Farm and Ranch Fencing: Provides durable boundary fencing for agricultural and ranch properties.
- Portable Pens: Ideal for temporary pens and rotational grazing systems.
- Rodeo and Event Use: Used in arenas, fairs, and livestock exhibitions for animal control.
- Loading and Sorting Areas: Supports livestock handling, sorting, and loading operations.
